- Model NO.: JZJ-9400
- Certification: CCC, CE, ISO9001
- Brand: Jzj
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Trademark: JZJ
- HS Code: 8419899090
- Type: Spray Booth
- Substrate: Steel
- Coating: Painting
- Heating Mode: Diesel
- Condition: New
- Origin: Yancheng Jiangsu
(1)(1).jpg)
High Quality Spray Booth Jzj-9400 From China
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
SPECIFICATION
|
Outside Dimension (mm) |
7006*5560*3420(L*W*H) |
Inside Dimension(mm) |
6900*4000*2650(L*W*H) |
|
Front Door(mm) |
3000*2600(W*H) |
Service Door (mm) |
650*1800(W*H) |
|
Total Power |
18KW |
||
|
Cabin System |
Wall panel |
50mm EPS sandwich panel, steel sheet thickness: 0.426mm |
|
|
Ceiling panel |
0.8mm galvanized steel sheet. |
||
|
Ramps |
3 pieces 2000*900mm ramps |
||
|
Basement |
300mm depth, three rows grids and two rows checkered plates. |
||
|
Glass |
5mm safety tempered glass |
||
|
Windows |
Square glass windows |
||
|
Air Make-up System |
Air Inlet fan system |
2*4kw YDW4.5L centrifugal fan |
|
|
Exhausted fan system |
1*7.5kw YDW5.6M centrifugal fan |
||
|
Air capacity for fresh air |
25000m3/h |
||
|
Exhausted ducting |
4meters straight ducting, one 90°elbow and one 45°elbow. |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5 / F5 |
||
|
Floor filter |
Fiber glass filter / G3 grade |
||
|
Exhausted fan filters |
Fiber glass filter and active carbon |
||
|
Heating System |
Heat exchanger |
SUS304 material, argon arc welding. |
|
|
Heating burner: |
RielloG20 diesel oil burner |
||
|
Heating productivity |
180000Kcal/h |
||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
||
|
Chimney ducting |
3 meters stainless ducting and one chimney elbow |
||
|
Max heating temperature |
80℃ |
||
|
fuel consumption |
6-8L/vehicle |
||
|
Lighting System |
Ceiling lights |
8 Units, each 4 * 18W LED lamps. Total 576 W |
|
|
Side lights |
8 Units, each 2 * 18W LED lamps, Total 288W |
||
|
Illumination |
900LUX |
||
|
Controlling System |
Switched control panel |
Spraying & baking switch, lighting switch, emergency stop, breakdown alarm, failure alarm |
|
