- Model NO.: JZJ-FB-9
- Certification: CCC, CE, ISO9001
- Coating: Painting
- Heating Mode: Diesel
- Condition: New
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419399090
- Type: Powder Coating Booth
- Brand: Jzj
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Color: Sea Blue, Red, Orange, White
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng, China
(1)(1).jpg)
9m High Quality Truck Spray/Paint Booth
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
SPECIFICATION
|
Outside Diemension(mm) |
9146*6396*4100(L*W*H) |
Inside Dimension(mm) |
9000*4500*3500(L*W*H) |
|
Front Door(mm) |
3300*3400(W*H) |
Service Door(mm) |
700*2000(W*H) |
|
Total Power |
30kw |
||
|
Cabin System |
Wall panel |
50mm EPS sanwich panel, steel sheet thickness: 0.426mm |
|
|
Ceiling panel |
0.8mm galvanized steel sheet |
||
|
Basement |
350mm depth, three rows grids and three rows checkered plates |
||
|
Ramps |
Four pieces 2000*800mm ramps |
||
|
Windows |
5mm safety tempered glass |
||
|
Air Make-up System |
Air inlet fan system |
2*7.5kw centrifugal fan |
|
|
Exhausted fan system |
1*11kw belt drive centrifugal fan |
||
|
Air capacity for fresh air |
40000m3/h |
||
|
Air capacity for exhausted air |
39000m3/h |
||
|
Air control method |
One manual damper for exhausted system |
||
|
Exhausted ducting |
4 meters straight ducting, one 90° |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5/F5 |
||
|
Floor filter |
Green fiber glass filter/G3 grade |
||
|
Exhausted fan filter |
Fiber glass filter and active carbon |
||
|
Heating System |
Heat exhanger |
SUS304 material, argon arc welding |
|
|
Heating burner |
Riello RS5S diesel burner |
||
|
Heating productivity |
260000Kcal/h |
||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
||
|
Chimney ducting |
6meters stainless ducting and one chimney cap |
||
|
Max heating temperature |
80ºC |
||
|
Fuel consumption |
10-12L/vehicle |
||
|
Lighting System |
Ceiling lights |
12Units, each 4*18W LED lamps, Total 864W |
|
|
Side lights |
10Units, each 2*18W LED lamps, Total 360W |
||
|
Illumination |
1000LUX |
||
|
Controlling System |
Switched control panel |
Spraying&baking switch, before baking flash-off, after baking flash-off, lighting switch, emergency stop, breakdown alarm, failure alarm |
|
