- Model NO.: JZJ-9200
- Certification: CCC, CE, ISO9001
- Brand: Jzj
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Trademark: JZJ
- HS Code: 8419899090
- Type: Spraying and Baking Spray Booth
- Substrate: Steel
- Coating: Painting
- Heating Mode: Diesel
- Condition: New
- Origin: Yancheng Jiangsu
(1)(1).jpg)
Economical Spray Booth Jzj-9200 From China
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
SPECIFICATION
|
Outside Dimension (mm) |
7006*5556*3450(L*W*H) |
Inside Dimension(mm) |
6900*4000*2650(L*W*H) |
|
Front Door(mm) |
3000*2600(W*H) |
Service door (mm) |
1800*650(W*H) |
|
Total Power |
10KW |
||
|
Cabin system |
Wall panel |
50mm EPS sandwich panel, steel sheet thickness: 0.426mm |
|
|
Basement |
300mm depth, two rows grids and three rows checkered plates. |
||
|
Ceiling panel |
0.8mm Galvanized steel sheet. |
||
|
Ramps |
Two pieces 2000*600mm ramps |
||
|
Glass |
4mm safety tempered glass |
||
|
Windows |
Rubber sealed glass window |
||
|
Air Make-up System |
Air Inlet fan system |
2*4kw centrifugal fan |
|
|
Exhausted fan system |
For option |
||
|
Ai capacity |
24000m3/h |
||
|
Air Flowing speed |
0.25m/s in empty booth |
||
|
Exhausted ducting |
4meters straight ducting, one 90°elbow and one 30°elbow. |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5 / F5 |
||
|
Floor filter |
fiber glass filter / G3 grade |
||
|
Exhausted fan Filters |
fiber glass filter and active carbon |
||
|
Heating System |
Heat Exchanger |
SUS304 material, argon arc welding. |
|
|
Heating burner: |
RielloG20 diesel oil burner(gas burner for option) |
||
|
Heating productivity |
180000Kcal/h |
||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
||
|
Chimney ducting |
3 meters stainless ducting and one chimney elbow |
||
|
Max heating temperature |
80ºC |
||
|
fuel consumption |
6-8L/vehicle |
||
|
Lighting System |
Ceiling lights |
8 Units, each 4 * 36W Philips lamps. Total 1152 W |
|
|
Side lights |
For option |
||
|
Illumination |
900LUX |
||
|
Controlling system |
Switched control panel |
Spraying & baking switch, lighting switch, emergency stop, breakdown alarm, failure alarm, pressure gauge |
|
