- Model NO.: JZJ-9100
- Certification: CCC, CE, ISO9001
- Coating: Painting
- Heating Mode: Diesel
- Condition: New
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419899090
- Type: Spray Paint Booth
- Brand: Jzj
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Color: Sea Blue, Red, Orange, White
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng Jiangsu
(1)(1).jpg)
Ce Proved Economical Car Spray/Paint
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
Specification
|
Outside Dimension (mm) |
7006*5460*3420(L*W*H) |
Inside Dimension(mm) |
6900*4000*2650(L*W*H) |
|
Front Door(mm) |
3000*2600(W*H) |
Service Door (mm) |
650*1800(W*H) |
|
Total Power |
9KW |
Total Weight |
3.8T |
|
Cabin System |
Wall panel |
50mm EPS sandwich panel, steel sheet thickness: 0.426mm |
|
|
Ceiling panel |
0.8mm galvanized steel sheet. |
||
|
Basement |
300mm depth, two rows grids and three rows checkered plates. |
||
|
Ramps |
Two pieces 2000*600mm ramps |
||
|
Glass |
5mm safety tempered glass |
||
|
Windows |
Square glass windows |
||
|
Air Make-up System |
Air inlet fan system |
1*7.5kw turbo fan |
|
|
Exhausted fan system |
For option |
||
|
Air capacity |
22000m3/h |
||
|
Exhausted ducting |
4 meters straight ducting, one 90°elbow and one 45°elbow. |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5 / F5 |
||
|
Floor filter |
Green fiber glass filter / G3 grade |
||
|
Exhausted fan filters |
Fiber glass filter and active carbon (for option) |
||
|
Heating System |
Heat exchanger |
SUS304 material, argon arc welding. |
|
|
Heating burner: |
BT14 diesel oil burner |
||
|
Heating productivity |
140000Kcal/h |
||
|
Spray to baking switch |
Pneumatic damper |
||
|
Chimney ducting |
3 meters stainless ducting and one chimney elbow |
||
|
Max heating temperature |
80℃ |
||
|
fuel consumption |
6-8L/vehicle |
||
|
Lighting System |
Ceiling lights |
8 Units, each 4 * 18W LED lamps. Total 576 W |
|
|
Side lights |
For option |
||
|
Illumination |
800LUX |
||
|
Controlling System |
Switched control panel |
Spraying & baking switch, lighting switch, emergency stop, breakdown alarm, failure alarm |
|
