- Model NO.: JZJ-9800
- Certification: CCC, CE, ISO9001
- Brand: Jzj
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419399090
- Type: Powder Coating Booth
- Substrate: Steel
- Coating: Painting
- Heating Mode: Electric
- Condition: New
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng Jiangsu
(1)(1).jpg)
Endothermic Heating Panel Spray Booth for Water Paint
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
SPECIFICATION
|
Outside Dimension (mm) |
7006*5856*3450(L*W*H) |
Inside Dimension(mm) |
6900*4500*2650(L*W*H) |
|
Front Door(mm) |
3000*2600(W*H) |
Service Door (mm) |
650*1800(W*H) |
|
Total Power |
53KW |
||
|
Cabin System |
Wall panel |
50mm rock-wool sandwich panel, steel sheet thickness: 0.6mm |
|
|
Ceiling panel |
Galvanized steel sheet. |
||
|
Basement |
300mm depth, middle with grids, side with checkered plates. |
||
|
Ramp |
Three pieces 2000*900mm ramps |
||
|
Glass |
6mm safety tempered glass |
||
|
Windows |
Square glass windows. |
||
|
Air Make-up System |
Air inlet fan system |
1*11kw turbo fan, proof-explosion motor, Ex rated |
|
|
Exhausted fan system |
1*11kw turbo fan, proof-explosion motor, Ex rated |
||
|
Air capacity |
32000m3/h |
||
|
Air control method |
One manual damper for air inlet and exhausted system |
||
|
Air ducting |
4 meters air duct, one flop damper and one weather hood |
||
|
Purification System |
Pre-filter |
G3 grade, Pockets filter |
|
|
Ceiling filter |
EU5 / F5 |
||
|
Floor filter |
Green fiber glass filter / G3 grade |
||
|
Exhausted fan filters |
Pocket filter or M green fiber glass filter and active carbon |
||
|
Heating System |
Endothermic Panels |
Endothermic Panels |
|
|
Spray to baking switch |
20N BELLIMO brand Electrical Damper |
||
|
Chimney ducting |
3 meters stainless ducting and one chimney elbow |
||
|
Max heating temperature |
80℃ |
||
|
Heating time |
7-9min(80℃) |
||
|
Lighting System |
Ceiling lights |
8 Units, each 4 * 18W LED lamps. Total 576 W |
|
|
Side lights |
8 Units, each 2 * 18W LED lamps, Total 288W |
||
|
Illumination |
1000LUX |
||
|
Controlling System |
Switched control panel |
Spraying & baking switch, before baking flash-off, after baking flash off, lighting switch, emergency stop, breakdown alarm, failure alarm |
|
