- Model NO.: JZJ-9800
- Certification: CCC, CE, ISO9001
- Brand: Jzj
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419399090
- Type: Powder Coating Booth
- Substrate: Steel
- Coating: Painting
- Heating Mode: Electric
- Condition: New
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng Jiangsu
(1)(1).jpg)
Economical Bus Spray
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
SPECIFICATION
|
Outside Dimension(mm) |
20156*6896*5600(L*W*H) |
Inside Dimension(mm) |
20000*5000*5000(L*W*H) |
|
Front Door(mm) |
4800*4800(W*H) |
Service Door(mm) |
700*2000(W*H)*2 |
|
Total Power |
117KW |
|
|
|
Cabin System |
Wall panel |
75mm EPS sandwich panel, steel sheet thickness: 0.6mm |
|
|
Ceiling panel |
50mm rock-wool sandwich panel |
||
|
Basement |
Dig 2 rows of pits basement |
||
|
Windows |
5mm safety tempered glass |
||
|
Air Make-up System |
Air inlet fan system |
6*9kw belt drive centrifugal fan |
|
|
Exhaust fan system |
3*18kw belt drive centrifugal fan |
||
|
Total air inlet capacity |
23000m3/h*6 |
||
|
Total air exhaust capacity |
42000m3/h*3 |
||
|
Air flowing speed |
0.25m/s in empty booth |
||
|
Air capacity control |
Each exhaust system with one manual damper |
||
|
Exhausr duct |
Each exhaust system with 1*6 meters straight duct, one flop damper |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5/F5 |
||
|
Floor filter |
Green fiber glass filter/G3 grade |
||
|
Exhausted fan filter |
Fiber glass filter and active carbon |
||
|
Heating System |
Heat exchanger |
SUS304 material, argon arc welding |
|
|
Heating burner |
3sets Riello RG5S diesel burner |
||
|
Heating prductivity |
260000Kcal/h*3 |
||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
||
|
Chimney ducting |
Each heating system with 1*6 meters stainless ducting and one chimney cap |
||
|
Max heating temperature |
80ºC |
||
|
Fuel consumption |
10-15L/vehicle |
||
|
Lighting System |
Ceiling lights |
26Units, each 4*18W LED lamps, Total 1872W |
|
|
Side lights |
28Units, each 2*18W LED lamps, Total 1008W |
||
|
Illumination |
900LUX |
||
|
Controlling System |
Switched control panel |
Spraying&baking switch, before baking flash-off, after baking flash-off, lighting switch, emergency stop, breakdown alarm, failure alarm |
|
