- Model NO.: JZJ-FB-20
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Color: Sea Blue, Red, Orange, White
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng Jiangsu
- Certification: CCC, CE, ISO9001
- Heating Mode: Diesel
- Condition: New
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419899090
(1)(1).jpg)
Passanger Spraybooth for 2000060005000 (JZJ-FB-20)
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
SPECIFICATION
|
Outside Dimension (mm) |
20156*8006*5800(L*W*H) |
Inside Dimension(mm) |
20000*6000*5000(L*W*H) |
|
|
Front Door(mm) |
4800*4500(W*H) |
Service door (mm) |
1800*650(W*H) |
|
|
Total Power |
120KW |
|||
|
Cabin system |
Wall panel |
75mm EPS sandwich panel, steel sheet thickness: 0.6mm |
||
|
Ceiling panel |
50mm rock-wool panel. |
|||
|
Windows |
4mm safety tempered glass |
|||
|
Air Make-up System |
Air Inlet fan system |
6*9kw centrifugal belt-drive fan, proof-explosion motor. |
||
|
Exhausted fan system |
3*18.5kw centrifugal belt-drive fan, proof-explosion motor. |
|||
|
Ai capacity for fresh air |
23000m3/h *6 |
|||
|
Air capacity for exhausted air |
42000m3/h *3 |
|||
|
Air Flowing speed |
0.25m/s in empty booth |
|||
|
Air Control method |
Each exhausted fan system with One manual damper fo |
|||
|
Exhausted ducting |
Each exhausted fan system with 6meters straight ducting, one |
|||
|
Purification System |
Pre-filter |
G3 grade |
||
|
Ceiling filter |
EU5 / F5 |
|||
|
Floor filter |
green fiber glass filter / G3 grade |
|||
|
Exhausted fan Filters |
M green fiber glass filter. |
|||
|
Heating System |
Heat Exchanger |
SUS304 material, argon arc welding. |
||
|
Heating burner: |
3 sets Riello RG5S diesel oil burner(gas burner for option) |
|||
|
Heating productivity |
260000Kcal/h/ burner |
|||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
|||
|
Chimney ducting |
Each heating system 6 meters stainless ducting for each |
|||
|
Max heating temperature |
80degrees |
|||
|
fuel consumption |
10-15L /vehicle |
|||
|
Lighting System |
Ceiling lights |
26 Units, each 4 x 36W, Total 3744 W |
||
|
Side lights |
28 Units, each 2 x 36W, Total 2016W |
|||
|
Illumination |
900LUX |
|||
|
Controlling system |
Micro-computerized programming system |
spraying&baking switch, lighting switch, emergency stop, |
||
