- Model NO.: JZJ-FB-18
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Color: Sea Blue, Red, Orange, White
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng Jiangsu
- Certification: CCC, CE, ISO9001
- Heating Mode: Diesel
- Condition: New
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419899090
(1)(1).jpg)
Bus Spray Booth for 1800050005000 (Model: JZJ-FB-18)
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
SPECIFICATION
|
Outside Dimension (mm) |
18156*6906*5800(L*W*H) |
Inside Dimension(mm) |
18000*5000*5000(L*W*H) |
|
Front Door(mm) |
4000*4500(W*H) |
Service door (mm) |
700*2000(W*H)*2 |
|
Total Power |
105KW |
||
|
Cabin system |
Wall panel |
75mm EPS sandwich panel, steel sheet thickness: 0.6mm |
|
|
No basement |
dig two rows |
||
|
Ceiling panel |
50mm rock-wool panel. |
||
|
Windows |
5mm safety tempered glass |
||
|
Air Make-up System |
Air Inlet fan system |
6*7.5kw centrifugal fan. |
|
|
Exhausted fan system |
3*18.5kw centrifugal belt-drive fan. |
||
|
Air capacity for fresh air |
108000m3/h |
||
|
Air capacity for exhausted air |
105000m3/h |
||
|
Air Flowing speed |
0.25m/s in empty booth |
||
|
Air Control method |
manual dampers for air inlet and exhausted system |
||
|
Exhausted ducting |
6 meters straight pipe and a flop damper |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5 / F5 |
||
|
Floor filter |
fiber glass filter / G3 grade |
||
|
Exhausted fan Filters |
fiber glass filter and active carbon |
||
|
Heating System |
Heat Exchanger |
SUS 304 material, argon arc welding. |
|
|
Heating burner: |
3 sets Riello RG5S diesel oil burner |
||
|
Heating productivity |
260000Kcal/h/ burner |
||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
||
|
Chimney ducting |
6 meters stainless ducting and one chimney elbow |
||
|
Max heating temperature |
80℃ |
||
|
fuel consumption |
10-15L /vehicle |
||
|
Lighting System |
Ceiling lights |
24 Units, each 4 x 18W LED lamps, Total 1728 W |
|
|
Side lights |
24 Units, each 2 x 18W LED lamps, Total 864 W |
||
|
Illumination |
900LUX |
||
|
Controlling system |
Micro-computerized programming system |
Spraying & baking switch,lighting switch, emergency stop, breakdown alarm, failure alarm |
|
