- Model NO.: JZJ-FB-12
- Airflow Direction: Fully Undershot-type
- Paint Mist Treatment: Dry-type
- Color: Sea Blue, Red, Orange, White
- Transport Package: Consist with International Shipping Packaging.
- Origin: Yancheng Jiangsu
- Certification: CCC, CE, ISO9001
- Heating Mode: Diesel
- Condition: New
- Trademark: JZJ
- Specification: CE, ISO
- HS Code: 8419899090
(1)(1).jpg)
Bus Spray Booth for 1200045003500 (Model: JZJ-FB-12)
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
SPECIFICATION
|
Outside Dimension (mm) |
12146*6906*4100(L*W*H) |
Inside Dimension(mm) |
12000*4500*3500(L*W*H) |
|
Front Door(mm) |
3300*3400(W*H) |
Service door (mm) |
1800*650(W*H) |
|
Total Power |
48KW |
||
|
Cabin system |
Wall panel |
70mm EPS sandwich panel, steel sheet thickness: 0.426mm |
|
|
Ceiling panel |
0.8mm Galvanized steel sheet. |
||
|
Windows |
4mm safety tempered glass |
||
|
Air Make-up System |
Air Inlet fan system |
4*5.5kw centrifugal fan |
|
|
Exhausted fan system |
2*11kw centrifugal belt drive fan |
||
|
Air capacity for fresh air |
15000m3/h *2 |
||
|
Air capacity for exhausted air |
30000 m3/h *2 |
||
|
Air Flowing speed |
0.25m/s in empty booth |
||
|
Air Control method |
One manual damper for exhausted system |
||
|
Exhausted ducting |
Each fan system with 4meters straight ducting, one 90°elbow |
||
|
Purification System |
Pre-filter |
G3 grade |
|
|
Ceiling filter |
EU5 / F5 |
||
|
Floor filter |
green fiber glass filter / G3 grade |
||
|
Exhausted fan Filters |
M green fiber glass filter and active carbon |
||
|
Heating System |
Heat Exchanger |
SUS304 material, argon arc welding. |
|
|
Heating burner: |
2 sets Riello G20 diesel oil burner(gas burner for option) |
||
|
Heating productivity |
180000Kcal/h x 2 |
||
|
Spray to baking switch |
20N BELIMO brand electrical damper |
||
|
Chimney ducting |
Each heating system with 6 meters stainless ducting and |
||
|
Max heating temperature |
80degrees |
||
|
fuel consumption |
10-12L/vehicle |
||
|
Lighting System |
Ceiling lights |
14 Units, each 4 x 36W Philips lamps ,Total 2016 W |
|
|
Side lights |
10Units, each 2 X 36W Philips lamps ,Total 720 W |
||
|
Illumination |
1000LUX |
||
|
Controlling system |
Micro-computerized programming system |
Spraying & baking switch, lighting switch, emergency stop, |
|
