- Model NO.: JZJ-MAX-4130
- Type: Double Cylinder Hydraulic Lift
- Lifting Capacity: 3.5T
- Driving Type: Hydraulic
- Certification: CE, ISO
- Driving Motor Number of Mechanical Lift: 1
- Shearing Lift Type: Small Shear Type
- Condition: New
- Brand: Jingzhongjing/Jzj
- Design: Scissor
- Trademark: JingZhongJing/JZJ
- Specification: CE, ISO
- Origin: Yancheng, Jiangsu
- HS Code: 8425429000
(1)(1).jpg)
Underground Scissor Car Lift with Ce Certification
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
SPECIFICATION
Features
1. Ultra-thin structure design for directly installed on the ground.
2. Four cylinders structure with minimum height of 110mm.
3. Anti-skid platform. Aluminum shell motor for overheat preventing.
4. Operating control system of 24V voltage.
5. With 24V limit switch.
6. Safe signal at 500mm above ground lowering.
7. Pneumatic lock provided.
8. Platforms can be extended for different length of vehicles.
9. Pass 115% dynamic and 150% static loading test.
1. Ultra-thin structure design for directly installed on the ground.
2. Four cylinders structure with minimum height of 110mm.
3. Anti-skid platform. Aluminum shell motor for overheat preventing.
4. Operating control system of 24V voltage.
5. With 24V limit switch.
6. Safe signal at 500mm above ground lowering.
7. Pneumatic lock provided.
8. Platforms can be extended for different length of vehicles.
9. Pass 115% dynamic and 150% static loading test.
|
Lifting capacity |
3500kg |
|
Lifting height |
2030mm(path 1700mm) |
|
Lifting time |
55-60s |
|
Platform length |
1440-2040mm |
|
Platform width |
550mm |
|
Power supply |
3/N/PE-380V/50Hz |
|
Motor power |
2.2Kw/380V/50Hz or 220V/50Hz(60Hz) |
|
Rated oil pressure |
23Mpa |
|
Rated air pressure |
0.6-0.8Mpa |
|
Weight |
850kg |
|
Packing size |
1700x570x740mmx2pcs 480x420x1050mm |
